  • Dayliff 200W 24VDC Monocrystalline Solar Module

Dayliff 200W 24VDC Monocrystalline Solar Module

Available

Quality Solar Module

Manufactured by Dayliff

The heart of all effective photovoltaic systems is an efficient and reliable solar module and there are none better than Dayliff PV Modules. All are sourced directly from leading global PV module manufacturers who comply with the highest standards of quality and durability and offer the following features:-

  • High efficiency multi/Mono crystalline solar cells with minimum 15% energy conversion rates to provide maximum power even at low irradiation levels
  • High transmission rate tempered glass with an anti-reflection coating to increase the power output and provide mechanical strength.
  • Multi function water proof junction box for easy connection.
  • 25 year power output warranty.
  • Global Certification.

Modules are sourced from world leading PV module manufacturers principally Trina, Yingli, Topray and Amerisolar who are all large scale vertically integrated manufacturers that process from silicon production to module assembly to ensure consistently high quality levels. Module types are recognised as quality products and are internationally certified by TUV Rheinland to ISO, CE and IEC standards as follows.

All Dayliff modules are manufactured to the highest standards and are guaranteed to provide reliable performance over long life spans. They are quality products in terms of both technology and performance and are ideal power sources for all types of solar applications.

THERMAL CHARACTERISTICS
Nominal Operating Cell Temperature: 43°+/-2°C
Temperature Coefficient Pmax: - 0.34%/°C
Temperature Coefficient Voc: - 0.25%/°C
Temperature Coefficient Isc: 0.04%/°C
Operational Temperature: -40˜+85°

ELECTRICAL DATA

Model Rated Power (W) Nominal Voltage (V) Peak Voltage (V) Open Circuit Voltage (V) Short Circuit Current (A) Number of Cells Dimensions (mm) Weight (kg)
A B C D E F
TP85M 85 12 20.9 24.4 4.45 36 875 528 715 350 100 23 2
TP125M 125 21.3 24.9 6.14 765 516 25 4
TP150M 150 24 37.2 43.3 4.45 64 910 875 750 588
TP200M 200 37.5 43.5 5.95 1190 1030 665 5
LO350M 350 34.4 40.4 10.18 60 1755 1038 1300 942 500 35 18
AS545M 545 41.6 49.8 13.98 144 2279 1134 1279 942 200 21
LO560M 560 43.5 51.6 13.94 2278 1134 1400 1093 439 30 27.2
TR660M 660 37.8 45.7 18.53 132 2384 1303 1261 492 35 33.3
TR665M 665 38.0 45.9 18.57 1303

Data is given at Standard Test Conditions: Irradiance 1000W/m² , spectrum AM 1.5 and 25°C cell temperature All modules Polycrystalline except when indicated ‘Mono’ for Monocrystalline

Read More

Key Features


Read More

1,599 ZMW

Dayliff 200W 24VDC Monocrystalline Solar Module is Manufactured by Dayliff

MPESA, Airtel Money, VISA & MasterCard

Delivery is within days

Warranty - Months

The heart of all effective photovoltaic systems is an efficient and reliable solar module and there are none better than Dayliff PV Modules. All are sourced directly from leading global PV module manufacturers who comply with the highest standards of quality and durability and offer the following features:-

  • High efficiency multi/Mono crystalline solar cells with minimum 15% energy conversion rates to provide maximum power even at low irradiation levels
  • High transmission rate tempered glass with an anti-reflection coating to increase the power output and provide mechanical strength.
  • Multi function water proof junction box for easy connection.
  • 25 year power output warranty.
  • Global Certification.

Modules are sourced from world leading PV module manufacturers principally Trina, Yingli, Topray and Amerisolar who are all large scale vertically integrated manufacturers that process from silicon production to module assembly to ensure consistently high quality levels. Module types are recognised as quality products and are internationally certified by TUV Rheinland to ISO, CE and IEC standards as follows.

All Dayliff modules are manufactured to the highest standards and are guaranteed to provide reliable performance over long life spans. They are quality products in terms of both technology and performance and are ideal power sources for all types of solar applications.

THERMAL CHARACTERISTICS
Nominal Operating Cell Temperature: 43°+/-2°C
Temperature Coefficient Pmax: - 0.34%/°C
Temperature Coefficient Voc: - 0.25%/°C
Temperature Coefficient Isc: 0.04%/°C
Operational Temperature: -40˜+85°

ELECTRICAL DATA

Model Rated Power (W) Nominal Voltage (V) Peak Voltage (V) Open Circuit Voltage (V) Short Circuit Current (A) Number of Cells Dimensions (mm) Weight (kg)
A B C D E F
TP85M 85 12 20.9 24.4 4.45 36 875 528 715 350 100 23 2
TP125M 125 21.3 24.9 6.14 765 516 25 4
TP150M 150 24 37.2 43.3 4.45 64 910 875 750 588
TP200M 200 37.5 43.5 5.95 1190 1030 665 5
LO350M 350 34.4 40.4 10.18 60 1755 1038 1300 942 500 35 18
AS545M 545 41.6 49.8 13.98 144 2279 1134 1279 942 200 21
LO560M 560 43.5 51.6 13.94 2278 1134 1400 1093 439 30 27.2
TR660M 660 37.8 45.7 18.53 132 2384 1303 1261 492 35 33.3
TR665M 665 38.0 45.9 18.57 1303

Data is given at Standard Test Conditions: Irradiance 1000W/m² , spectrum AM 1.5 and 25°C cell temperature All modules Polycrystalline except when indicated ‘Mono’ for Monocrystalline
